SHP to DGN conversion

The tool allows you to convert ESRI SHP format data into a DGN V8 drawing. It supports splitting objects into layers, adding labels from attributes and placing cells to point objects – all without the need for manual editing.

How does it work?

• You upload a ZIP archive containing SHP data (including the necessary *.dbf, *.shx, etc.).
• Optionally specify which attributes to use for layers, labels or cells
• Select a seed file and add a cell library if necessary
• After processing, you will receive a DGN drawing and a report with conversion information

What do you get?

• DGN drawing – the converted drawing with the correct layers, labels and cells according to the input data
• Report.txt – summary of conversion statistics (number of objects, attributes used, warnings)

Full support of attribute export control:

1. layers named according to the selected attribute
2. labels consisting of one or more attributes
3. cells to points according to the name from the attribute (e.g. for adding symbols in the map)
